28
Item Part
Qt
y
Description
Ite
m
Part Qty Description
85 DF2500H-31201-A 2 Bottom rubber A 127 14306 1 Fuel filler cap comp
86 DF2500H-31202-A 2 Bottom rubber B 128 14303 1 Fuel sensor
87 GBT6177-N-8 4 Flange nut M8 129 GBT819-B-5 2 Screw M5×10
88 GBT889-N-8 10 Flange nut M8 130 14313 1 GASKET,FUEL SENSOR
89 DF2500H-14304-A 1 Rubber Screws, Fuel Tank 131 14311 4 Washer
90 34107 1 Earth terminal set 132 14305 4 Collar
91 34206-100 1 Circuit breaker 133 14304 4 Cushion
92 34204-003 1 4-holes Socket 134 DJ168FD-14007-C 1 Outlet pipeφ4.5×165
93 34204-005 1 3-holes Socket 135 DJ168F-14008-A 2 Tube clip
94 20140 4 Plain Washer 136 DF2500H-14302-A 1 Fuel cock
95 34204-038 1 Output Set, DC A 137 DF2500H-14400-E 1 Muffler
96 34208-004 1 Over-current protector, DC 138 DJ188F-14010-A 1 Gasket , Exhaust Pipe
97 34204-039 1 Output Set, DC B 139 DF2500H-14009 1 Exhaust Pipe
98 34203-004 1 Engine switch 140 GB5787-B-8 2 Flange bolt M8×25
99 XP4400-34101-A 1 Control panel 141 DJ168F-14006-A Muffler Gasket
100 34213-001 1 Sub Wire Harness Assay 142 DF2500H-14018-B 1 Outer Hood
101 34205-001 1 Voltmeter 143 DF2500H-31019-B 2 φ3 Clip
102 34210-001 1 Rectifier bridge 30A 144 31017-F 2 Wheel comp
103 34102-A 1 Control panel case 145 DF3000H-31018-F 1 Well shaft
104 34109 1 Boot, main wire harness 146 DF3000H-31070-E 2 Support
105 34117 1 Boot, AC output wire 147 GBT889-N-6 2 Flange nut M6
106 34212-001 1 Boot, main wire harness 148 DF9000H-31204-A 2 Rubber feet
107 GBT6170-N-8 6 Flange nut M8 149 DF6500H-31016-A 2 Rubber Coat, Handle
108 GBT5789-B5-16 8 Flange bolt M5×16 150 DF3800H-31058-C 2 Handle
109 DF1800H-33006-B 1 Generator end cover 151 GBT889-N-8×20 10 Flange bolt M8×20
110 DF3500H-33015-A 4 Flange bolt M6×156 152 DFD3000H-31021-B 1 Axle
111 DF1800H-33005-A 1 GENERATOR STAY 153 34202-006 1 Transfer Switch
112 DF3500H-33001 1 BRUSH ASSEMBLY
154
DJ170N-B
1 Gasoline engine
113 DF3500H-33002 1 Conecting Plate
155
XP4400-31100-B
1 Frame com
114 DF2500H-33011-A 1 Voltage regulator
115 DF3500H-33003-A 1 Bolt M8×220
116 GBT93-LW-8 1 Plain washer φ8
117 GBT97-W-8 2 Plain Washer
118 GB276-89-6204 1 Bearing 6204-2RS
119 DF3500H-33110-B 1 ROTOR ASSEMBLY
120
DF3000H33103-B-
23602
1 Stator & Rotor Assy.
121 DF2500H-33023 1 Generator fan
122 DF3500H-33129 1 Stator cover
123 DF3500H-33120 1 Stator Assy.
124 DF2500H-14322-D 1 rubber belt
125 DF2500H-14300-B 1 Fuel tank
126 14307 1 Fuel filter
