CRANK PLATE SUB-ASSEMBLY PARTS
Item Qty. Description Part Number
38 1 Crank Plate, Hard Coated B4-147-0031-P
39 1 Bearing, Crank Plate P4-903-0020
40 2 Cam Follower P4-903-0018
41 1 Cam Follower, Eccentric P4-903-0019
42 4 Spring Lock Washer 63-E-07
43 4 Hex Nut 41-E-57
47 4 Crank Plate Plugs A4-139-0023
48 1 Pallet Pin A4-066-0044
CRANK PLATE SUB-ASSEMBLY DRAWING
20
