Owner’s Manual – Dux Electric Boosted Solar
14
H3161 025248 Rev. D
COLLECTOR
SENSOR
BOTTOM
SENSOR
TOP
SENSOR
MODULE
SENSOR
Attach collector
sensor cable to
terminal block
COLLECTOR
SENSOR
BOTTOM
SENSOR
TOP
SENSOR
MODULE
SENSOR
Terminal block secured
to timber or metal truss
inside roof cavity
Collector sensor connection for
models 2F136S, 3F136S, 4F136S
