Owner’s Manual – Dux Electric Boosted Solar
16
H3161 025248 Rev. D
Panel Management
(Available only for models 2F136SD, 3F136SD and 4F136SD)
Warning: The point of discharge from each drain
line shall be located so that the release of steam
or hot water does not cause a nuisance, is readily
discernible and incurs no risk of damage to the
building or injury to persons.
Install water
heater to
allow easy
access and
removal of the
solar module
cover
Pipes with
flared fittings.
Remove pipes
from valve if
soldering is
required.
Plumb to waste as per AS3500.4
Do not connect to the the PTR
drain line.
The electrical supply to the
pump module must be continu-
ously available. Off Peak power
must not be used.
