DV Systems C15 User Manual

C1015-II-C
Jun ‘21
- 9 -
Installation - Electrical
 Ensure that all wiring, fusing, etc is done in a manner that meets with the appropriate codes and
regulations.
 See the sales drawings and electrical schematic contained in this manual for information about Motor
nameplate amps, this is used to determine the appropriate Disconnect / Breaker and Wiring sizes.
 Units equipped with Variable Speed Drives (VSDs) MUST use FAST-ACTING FUSES. Refer to the
table below for fuse sizes.
General Information.
It is your responsibility to ensure that the Compressor
Unit is electrically connected in a safe and correct
manner. Any electrical work should be carried out
by a competent Electrician, and be done in such
a way that it meets all applicable Codes and
Regulations.
Ensure that a suitable Fused Disconnect or Breaker
(by others than DV Systems) is installed in the
electrical supply before the Compressor Unit.
Ensure that a suitable Fused Disconnect or Breaker
is sized and installed according to the appropriate
local electrical codes.
Electrical wiring and conduit from the building supply,
through the Compressor Cabinet, and to the Switch
in the Compressor Control Panel, must be rated for
90°C (194 °F) or higher.
Failure to observe any of the above precautions could result in severe personal injury or death,
and/or damage to the Unit.
 Failure to correctly connect the Compressor to
your building's electrical services may result
in serious personal injury or damage to the
equipment.
 Install all covers and panels before applying
power to the Unit.
 Failure to install proper fuse protection may
void the unit warranty.
 Before servicing the Unit, ensure the power
source has been shut down and locked off.
 Read and understand the information
contained in this manual before installing or
operating the Unit.
 This product must be connected to a
grounded, metallic, permanent wiring system,
or an equipment-grounding terminal or lead on
the product.

Fusible Disconnects.
VSD Units:
Voltage
Fuse
Type
Fuse
Amp
DV Fuse
Part No.
DV Disconnect Kit
(Disconnect +
Fuses)
200
HSJ,
DFJ
60
F060
FD-060
230
50
F050
FD-050
460
25
F025
FD-025
575
20
F020
FD-020
Fixed Speed Units:
Use TIME-DELAY type fuse.
Max. Allowable Fuse =
1.75 x Motor Full Load Amp
