DVO ONYX DC - Air Service Procedure - Fluid Addition; Lock Ring, End Plug Tightening and Fluid Addition

ONYX DC FULL SERVICEONYX DC FULL SERVICE13
29.
28.
30.
Pour 5cc’s of 7.5wt suspension fluid into the
stanchion tube above the air piston.
Place the lock ring back onto the plug.
Apply a thin layer of Loctite to the threads of the
end plug. Tighten with the pin spanner wrench.
