ONYX DC FULL SERVICEONYX DC FULL SERVICE7
10.
11.
12.
Now you can separate the upper assembly from
the casting.
Remove the foam ring from under the seal with a
small pick. Then remove the pressure spring on
the upper seal lips.
Place a flathead screwdriver under the seal lip
and pry the seal out of the casting.
NOTE: To prevent any damage to the casting, you
can place a rag or towel under the screwdriver.
Seal Service B
