DWK WHEATON R2P 2.0 - PARTS LISTS AND ILLUSTRATIONS

WHEATON® R2P
™
2.0 Bottom Drive Roller Apparatus
4
DWK Life Sciences | 856.825.1100 | www.dwk.com | P/N 50099817 Rev. 11/2021
PARTS LISTS AND ILLUSTRATIONS
FIGURE A – MAIN ASSEMBLY - WRBXR5XX0-A-B
FIGURE B – MAIN ASSEMBLY - WRBXR5XX0-A-B
FIGURE C – MAIN ASSEMBLY - WRBXR5XX0-C-J
FIGURE D – MAIN ASSEMBLY - WRBXR5XX1-C-J
FIGURE E – BASE ASSEMBLY WITH UPRIGHTS - WL055618
FIGURE F AND G – DRIVE UNIT - WL058604, WL058639, WL058620, WL058640
FIGURE H – FRONT RAIL ASSEMBLY - WL055613
FIGURE I – REAR RAIL ASSEMBLY - WL055612
FIGURE J – ROLLER ASSEMBLY - WL055614
FIGURE K – DRIVE PULLEY & SENSORS - WL058613, WL058614
FIGURE L – MAINS FUSE REPLACEMENT
FIGURE M – BOTTLE SPEED VALIDATION
EMI DECLARATION AND WEEE NOTICE
