WHEATON® R2P
™
2.0 Bottom Drive Roller Apparatus
44
DWK Life Sciences | 856.825.1100 | www.dwk.com | P/N 50099817 Rev. 11/2021
REGISTER
UNITS
DESCRIPTION
4:00001
value:1
Motor Gear Ratio
4:00002
0.1 mm
Bottle Diameter
4:00003
0.01 RPM
Target Bottle Speed (set-point)
4:00004
0.01 RPM
Speed Tolerance
4:00005
seconds
Reverse Interval
4:00006
4:00007
sec/fs
Ramp Rate
4:00008
0.1 *C
Low Temperature Threshold
4:00009
0.1 *C
High Temperature Threshold
4:00010
seconds
Calendar Date as seconds from 1/1/2000
4:00011
4:00012
<reserved>
4:00013
Front Panel Lock/Unlock
Write the value 5555 (decimal) to lock the front panel.
Write the value 0 (decimal) to unlock the front panel.
All other values are ignored.
Reading the register returns the panel's state.
Modbus over the Ethernet Network
The R2P 2.0 comes equipped to interface with Modbus TCP/IP also known as Modbus TCP. This is a
variant of the Modbus industrial communication for use over Ethernet local area networks. Most
SCADA systems recognize this communication protocol and there are many drivers available to
operate on OPC enabled architectures.
