WHEATON® Standard Roller Apparatus
14
DWK Life Sciences | 856.825.1100 | www.dwk.com | P/N 50099786 Rev. 11/2021
Front Panel Navigation
All functions of the Top Drive Standard Roller Apparatus can be controlled through the front panel.
Functions are divided into three main modes e.g. the Operation Mode, Setup Mode and Factory Mode.
FIGURE 1 – FRONT PANEL NAVIGATION
Navigating between the three main screens is done through the four push buttons on the edge of the
display.
FIGURE 2 – DISPLAY INTERFACE
Optional Alarm
Output Jack
