WHEATON® Standard Roller Apparatus
3
DWK Life Sciences | 856.825.1100 | www.dwk.com | P/N 50099786 Rev. 11/2021
PARTS LISTS AND ILLUSTRATIONS
FIGURE A – MAIN ASSEMBLY 52 POS TOP DRIVE STANDARD ROLLER – WSTPF511X-A-J
FIGURE B – MAIN ASSEMBLY 86 POS TOP DRIVE STANDARD ROLLER – WSTPF811X-A-J
FIGURE C – ASSEMBLY, BASE WITH UPRIGHTS – WL055693
FIGURE D – ASSEMBLY, BASE WITH UPRIGHTS & DECKS – WL055702
FIGURE E – ASSEMBLY, FRONT RAIL – WL055613
FIGURE F – ASSEMBLY, FRONT RAIL – WL055704
FIGURE G – ASSEMBLY, REAR RAIL – WL055612
FIGURE H – ASSEMBLY, REAR RAIL – WL055703
FIGURE I – ASSEMBLY, DECK – WL055614
FIGURE J – ASSEMBLY, DECK – WL055701
FIGURE K – ASSEMBLY, TOP FRONT RAIL – WL055691
FIGURE L – ASSEMBLY, TOP FRONT RAIL – WL055682
FIGURE M – ASSEMBLY, TOP REAR RAIL – WL055690
FIGURE N – ASSEMBLY, TOP REAR RAIL – WL055683
FIGURE O – ASSEMBLY, TOP DECK – WL055689
FIGURE P – ASSEMBLY, TOP DECK – WL055700
FIGURE Q AND R – ASSEMBLY DRIVE UNIT – WL058584, WL058633, WL058601, WL058634
FIGURE S – ASSEMBLY – WL058605, WL058585, WL058609, WL058589
FIGURE T – ASSEMBLY – WL058607, WL058588, WL058608, WL058590
FIGURE U – MAINS FUSE REPLACEMENT
FIGURE V – BOTTLE SPEED VALIDATION
EMI DECLARATION AND WEEE NOTICE
