WHEATON® Standard Roller Apparatus
32
DWK Life Sciences | 856.825.1100 | www.dwk.com | P/N 50099786 Rev. 11/2021
FIGURE D – ASSEMBLY, BASE WITH UPRIGHTS & DECKS – WL05570
FIGURE D – ASSEMBLY, BASE WITH UPRIGHTS & DECKS – WL05570
ITEM
QTY.
DWK NO.
DESCRIPTION
1
12
I052861
RAIL, SIDE SUPPORT
2
1
I052858
BASE
3
2
WI058092
CASTER 3.5 IN. NON-MARKING WITH BRAKE
4
2
WI058093
CASTER 3.5 IN. NON-MARKING, NO BRAKE
5
168
I052370
WASHER, STAR, 1/4 IN., INT. TOOTH
6
152
I052363
1/4-20 X 1/2 IN., BOLT
7
16
50030016
1/4-20 X 5/8 IN., BOLT
8
16
50027727
1/4 X 5/8 IN. WASHER
9
2
I052860
RAIL, LEFT UPRIGHT
10
2
I052859
RAIL, RIGHT UPRIGHT
