WHEATON® Standard Roller Apparatus
49
DWK Life Sciences | 856.825.1100 | www.dwk.com | P/N 50099786 Rev. 11/2021
FIGURE S – ASSEMBLY – WL058605, WL058585, WL058609, WL058589
ITEM
QTY.
DWK NO.
DESCRIPTION
USED ON
1A
84
I052714
PULLEY, TOOTHED
WL058605, WL058609
1B
86
I052714
PULLEY, TOOTHED
WL058585, WL058589
2
2
I050990
ASSEMBLY, TRIP PULLEY, MAGNETIC
WL058605, WL058609
3
20
I051188
BELT 187L025
4
2
I052719
BELT, DRIVE,225L025
5
42
I052737
BELT, ROUND ENDLESS, 4 1/2 IN. DIA.
6
20
I051433
SPACER, 3/8 IN., #6-32 THREAD
7
2
WL055632
GUARD, BELT, 11 DECK
8
20
I052273
WASHER, STAR, #6, INTERNAL TOOTH
9
2
I052338
WASHER, STAR, #10, INTERNAL TOOTH
10
2
I052370
WASHER, STAR, 1/4 IN., INTERNAL TOOTH
11
4
50029959
WASHER, STAR, #8, INTERNAL TOOTH
12
4
50029863
WASHER, STAR, #4, INTERNAL TOOTH
WL058605, WL058609
13
20
I052240
SCREW, #6-32 X 3/8 IN.
14
2
I052324
SCEW,10-32 X 1-1/4 IN.
15
4
50029922
SCREW, #8-32 X 3/8 IN.
16
4
50029858
SCREW, #4-40 X 3/8 IN.
WL058605, WL058609
17
2
50030016
1/4-20 X 5/8 IN., BOLT
18
1
50026982
MOTOR BELT GUARD
19
1
I054216
ASSEMBLY, DRIVE PULLEY, 1/2 IN. DIAMETER HOLE
20
4
I052353
SCREW, SET, #10-32 X 1/4 IN.
21
2
50028829
LABEL, PINCH AND CRUSH
22
1
50099276
LABEL, UL APPROVED
23
1
50028394
LABEL, MET NRTL LISTED
24
2
WI056898
UNIVERSAL ROTATION ALARM
WL058605, WL058609
25
4
50029894
NUT, HEX, #4-40
WL058605, WL058609
26
2
50099517
FERRITE
WL058605, WL058609
27
8
I051479
CABLE TIE
WL058605, WL058609
28
1
50028416
LABEL, CE (MARK)
WL058609, WL058589
29
1
50091156
LABEL, WEEE
WL058609, WL058589
30
3
50099798
18 MM HOLE PLUG
WL058585, WL058589
