FIGURE T – ASSEMBLY – WL058607, WL058588, WL058608, WL058590
ITEM
QTY.
DWK NO.
DESCRIPTION
USED ON
1
20
I052240
SCREW, #6-32 X 3/8 IN.
2
4
50029922
SCREW, #8-32 X 3/8 IN.
3
2
I052324
SCW,10-32 X 1-1/4 IN.
4
4
50029858
SCREW, #4-40 X 3/8 IN.
WL058607, WL058608
5
1
I052900
MOTOR, BELT GUARD
6
4
50029959
WASHER, STAR, #8, INTERNAL TOOTH
WL058607, WL058608
7
2
I052370
WASHER, STAR, 1/4 IN., INTERNAL TOOTH
8
2
I052338
WASHER, STAR, #10, INTERNAL TOOTH
9
20
I052273
WASHER, STAR, #6, INTERNAL TOOTH
10
4
50029863
WASHER, STAR, #4, INTERNAL TOOTH
WL058607, WL058608
11
1
50099276
LABEL, UL APPROVED
12
1
50028394
LABEL, MET NRTL LISTED
13
2
50028829
LABEL, PINCH AND CRUSH
14
2
50099517
FERRITE
WL058607, WL058608
15
2
50030016
1/4-20 X 5/8 IN., BOLT
16
1
I054216
ASSEMBLY, DRIVE PULLEY, 1/2 IN. DIA. HOLE
17
4
I052353
SCREW, SET, #10-32 X 1/4 IN.
18
2
I051188
BELT 187L025
19
2
WL055632
GUARD, BELT, 11 DECK
20
20
I051433
SPACER, 3/8 IN., #6-32 THREAD
21
76
I052737
BELT, ROUND ENDLESS, 4 1/2 IN. DIA.
22
20
I051188
BELT 187L025
23A
162
I052714
PULLEY, TOOTHED
WL058607, WL058608
23B
164
052714
PULLEY, TOOTHED
WL058588, WL058590
24
2
I050990
ASSEMBLY, TRIP PULLEY, MAGNETIC
WL058607, WL058608
25
2
WI056898
UNIVERSAL ROTATION ALARM
WL058607, WL058608
26
4
50029894
NUT, HEX, #4-40
WL058607, WL058608
27
8
I051479
CABLE TIE
WL058607, WL058608
28
1
50028416
LABEL, CE (MARK)
WL058608, WL058590
29
1
50091156
LABEL, WHEELIE BIN
WL058608, WL058590
30
3
50099798
18 MM HOLE PLUG
WL058588, WL058590
