Revision: Device revision.
Model Number: Device model number.
Figure 27. Diagnostics Page - Dymax
Emitter Control Page
Emitter1 On/Off: Allows the user to turn Emitter1 on or off.
Emitter1 Power: Allows the user to turn adjust the power level for Emitter1
(1 – 100%).
Emitter2 On/Off: Allows the user to turn Emitter2 on or off.
Emitter2 Power: Allows the user to turn adjust the power level for Emitter2
(1 – 100%).
Emitter3 On/Off: Allows the user to turn Emitter3 On or Off.
Emitter3 Power: Allows the user to turn adjust the power level for Emitter3
(1 – 100%).
Emitter4 On/Off: Allows the user to turn Emitter4 On or Off.
Emitter4 Power: Allows the user to turn adjust the power level for Emitter4
(1 – 100%).
