BlueWave® MX-MIM User Guide
Connections
Based on the installation needs, review the connections to be made as part of a planned
installation utilizing any safety features required.
Figure 1. BlueWave® MX-MIM - Top View
Figure 2. Bottom View
Emitter Connectors
1 thru 4
Power
Receptacle
Ethernet Connector
Emitter Interlocks
