BlueWave® MX-MIM User Guide
45
Specifications
Property
Specification
Power Supply Input
24 VDC ± 1% @ 10A Max (300W supply recommended)
Emitter Channels
Supports up to four MX-series emitters
Network Interface
One 10/100 base-T Port
Supports EtherNet/IP, and PROFINET
Please Note: Device Level Ring (DLR) is not supported
Physical Dimensions
4.96” H x 7.32” W x 3.50” D
Mounting
DIN Rail; 35-mm top-hat style
Weight
2.035 lbs.
Cooling
Internal fan, no filter
Operating
Environment
Indoors, +10 to +40°C, 0-80% relative humidity, non-condensing
at sea level
Not qualified for outdoor use
Storage Conditions
-20 to +50°C, 0-75% relative humidity, non-condensing, at sea
level
Short Term Transport
-40 to +50°C
Figure 39.Dimensions
