Emitters 1-4
Power and communication are supplied through an emitter interface cable via one of
the four emitter interface connectors located on the front/lower tiered portion of the
enclosure. Please refer to “Parts & Accessories” for available cable lengths. Each cable
connector end provides a screw-down retention feature to ensure positive connections
are maintained during operation.
CAUTION: Power to the controller must be off when connecting or
removing the emitter interconnect cables.
Ethernet Port
One 10/100 EtherNet port provides communications across the user’s network to the
host PLC. The use of shielded cables is required to ensure reliable communications
(Table 1).
Table 1. Communication
