Dymo LabelManager PnP - Inserting the Battery

2
Become familiar with the features shown in Figure 2.
Inserting the Battery
The label maker is powered using a rechargeable lithium-ion battery.
To insert the battery
1 Open the side cover of the label maker.
2 Remove the battery compartment cover.
See Figure 3.
3 Insert the battery into the battery
compartment as shown.
4 Replace the battery compartment cover.
5 Close the side cover of the label maker.
NOTE Remove the battery if the label maker will
not be used for a long period of time.
1
Power button/Status light
4
USB port
7
Battery compartment
2
Cutter button
5
Side cover
8
Label compartment
3
Label exit slot
6
Cleaning tool
9
Serial Number label
Figure 2
7
3
4
2
6
9
8
5
1
Figure 3
