36
XTL
®
300
User Guide
A101 A101 A101 A102 A102 A102 A103 A103 A103
This setting is saved with your label file.
To turn off collation
1 Press and hold to display the print options menu.
2 Select Collate and then select Don’t collate labels.
3 Select Done and then press .
Mirror
The mirror option allows you to print the contents of your label
backwards, from right to left, as you would see the contents of
your label in a mirror.
This setting is not saved with your label file.
To print from right to left
1 Press and hold to display the print options menu.
2 Select Mirror and then select Mirror content.
3 Select Done and then press .
Cut Labels
When printing multiple copies, the label maker pauses between each label
allowing you to cut before printing the next label.
You can change this setting so that the label maker prints all labels continuously
and you can cut once at the end. A label separator cut mark is printed between
each label to show where each label should be cut.
To choose when to cut multiple labels
1 Press and hold to display the print options menu.
2 Select Cut labels.
3 Select one of the following:
• All labels
• Each label (default)
4 Select Done and then press .
Feed
You may need to feed additional label material before you cut a label or feed a
label that does not advance from the label exit slot properly.
To feed the label
1 Press and hold to display the print options menu.
2 Select Feed to advance the label by 1/4” (6 mm).
Setting the Default Barcode
The default barcode type will be inserted automatically each time you insert a
barcode on a label. The factory default barcode type is Code 128.
