23
Figure 2
Care and Maintenance
Burner Assembly
Removing The Burner Assembly
1. Make sure all control knobs are in the
OFF position, gas supply valve is closed,
and the gas hose is disconnected from the
gas supply.
2. Open lid and remove warming rack,
cooking grates, and heat tents.
3. Remove hinge pin as shown in Figure 1.
4. Slide main burners and SearPLUS™
burner out of rebox.
5. Detach ignition wire from electrode in
Figure 2.
Figure 1
To Next Page
