Package Contents
PART DESCRIPTION QTY.
A Hood Handle 1
B Temperature Gauge 1
C Temperature Gauge Bezel 1
D Grill Body Assembly 1
E Control Knob 5
F Grease Pan 1
G Grease Cup 1
H Warming Rack 1
I Cooking Grate For Main Burner 2
J Heat Tent For Main Burner 4
K Left Side Table 1
L Cooking Grate For Sear Burner 1
M Heat Tent For Sear Burner 1
N Right Side Burner Body 1
O Left Leg Assembly 1
J
I
C
B
A
D
E
K
L
M
N
Q
G
H
O
R
Z
F
P
T
S
U
A1
X
Y
W
V
D1
C1
B1
E
E1
PART DESCRIPTION QTY.
P Leg End Cap 2
Q Side Exclusion Bar 1
R Tank Brace 1
S Cart Rear Support 1
T Cart Front Panel - Upper 1
U Cylinder Exclusion 1
V Cart Front Panel - Lower 1
W Axle 1
X Wheel 2
Y Right Leg Assembly 1
Z Condiment Tray 1
A1 Control Knob for Sear Burner 1
B1 Side Burner Grate 1
C1 Side Burner 1
D1 Side Burner Control Knob Bezel 1
E1 Tank Retention Fixed Wire 2
