Dyna-Glo KFA50H - Unpacking and Assembly

4
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
Figure 5. KFA125H/KFA210H2 MODELS
Handle
Cord Wraps
(KFA75H Model Only)
Hardware Kit
HW-KFA1001
3. UNPACKING AND ASSEMBLY
1. REMOVE THE HEATER AND ALL PACKING MATERIALS FROM THE BOX. (Fig. 4 and 5)
NOTE : Save the shipping carton and packing materials for future storage.
Figure 4. KFA50H / KFA75H MODELS
Wheel Support Fram
Threaded Axle
Rear Handle
Handle
Cord Wrap
e No
No
No
No
No Yes Yes
Wheel No No Yes Yes
No Yes Yes
No Yes Yes
Yes Yes Yes
Front Handle No No Yes
Yes
Yes
Yes
Hardware kit : HW-KFA1001 Yes No No
Yes No No
Hardware kit : HW-KFA1016 No No Yes Yes
Front Handle
Wheel Support Frame
Rear Handle
Threaded Axle
Wheels
(10” Flat Free)
Cord Wraps
Screws Flange Screws
Nuts Cap Nuts S Cap Nuts LBushings
Hardware Kit : HW-KFA1016
KFA50H KFA75H KFA125H KFA210H2
