DYNACO SCA-80 User Manual

Page 15 of 15
Resistor Color Code
Figure 11-demonstrating the resistor color code
Here’s an extreme close-up of a ¼ W metal film 20K (20,000) Ohm resistor, designated
by the standard resistor color code.
The colors map to numbers:
Color Number
Black 0
Brown 1
Red 2
Orange 3
Yellow 4
Green 5
Blue 6
Violet 7
Gray 8
White 9
The color band positions have the following meaning:
Position Meaning
1 Left-most Digit (e.g. most significant)
2 Next digit to the right
3 Next digit to the right.
4 Number of zeros that follow the three digits, unless:
 Band 4 is gold => multiply by 0.1
 Band 4 is silver=> multiply by 0.01
**Yellow Tolerance:
 Brown =>1%
 Red => 2%
 Gold=> 5%
 Silver=>10%
 No band=>20%
