Figure 2-Guide to component installation
Designation Value Color Code Done()
R1 649 Blue, Yellow, White, Black, Brown
R2 - Leave this slot empty
R3 649 Blue, Yellow, White, Black, Brown
R4 60K4 Blue, Black, Yellow, Red, Brown
R5 11K Brown, Brown, Black, Red, Brown
R6 - Leave this slot empty
R7 10K Brown, Black, Black, Red, Brown
