Dynacord CL 800 User Manual

10
MAINS OPERATION & RESULTING TEMPERATURE
CL1600
U
mains
[V]
I
mains
[A]
P
mains
[W]
P
out
[W]
Pd
(6)
[W]
BTU/hr
(4)
idle 230V 0,5 65 - 65 220
Max. Output Power @ 8Ω
(1)
230V 8,0 1440 2 x 500 440 1500
Max. Output Power @ 4Ω
(1)
230V 13,2 2520 2 x 800 920 3140
1/3 Max. Output Power @ 4Ω
(1)
230V 7,5 1360 2 x 266 828 2825
1/8 Max. Output Power @ 4Ω
(1)
230V 3,0 520 2 x 100 320 1090
1/8 Max. Output Power @ 4Ω
(2)
230V 3,3 570 2 x 100 370 1260
1/8 Max. Output Power @ 4Ω
(2),(5)
254V 3,6 660 2 x 120 420 1435
1/8 Max. Output Power @ 4Ω
(3)
230V 3,8 580 2 x 100 380 1295
1/8 Max. Output Power @ 4Ω
(3),(5)
254V 4,1 695 2 x 120 455 1550
Normal Mode (-10dB) @ 4Ω
(1)
230V 2,8 470 2 x 80 310 1060
Rated Output Power (0dB) @ 4Ω
(1)
230V 12,5 2360 2 x 700 960 3275
Alert (Alarm) Mode (-3dB) @ 4Ω
(1)
230V 8,8 1610 2 x 350 910 3105
Max. Output Power @ 2Ω
(1)
230V 20,0 4000 2 x 1100 1800 6140
1/8 Max. Output Power @ 2Ω
(1)
230V 4,5 815 2 x 138 540 1840
1/8 Max. Output Power @ 2Ω
(2)
230V 5,0 825 2 x 138 550 1875
1/8 Max. Output Power @ 2Ω
(3)
230V 5,4 905 2 x 138 630 2150
CL2000
U
mains
[V]
I
mains
[A]
P
mains
[W]
P
out
[W]
Pd
(6)
[W]
BTU/hr
(4)
idle 230V 0,6 72 - 72 246
Max. Output Power @ 8Ω
(1)
230V 10,0 1712 2 x 600 512 1747
Max. Output Power @ 4Ω
(1)
230V 16,3 2991 2 x 1000 991 3381
1/3 Max. Output Power @ 4Ω
(1)
230V 9,7 1646 2 x 333 979 3342
1/8 Max. Output Power @ 4Ω
(1)
230V 4,0 617 2 x 125 367 1252
1/8 Max. Output Power @ 4Ω
(2)
230V 4,4 696 2 x 125 446 1522
1/8 Max. Output Power @ 4Ω
(2),(5)
254V 4,8 815 2 x 151 513 1749
1/8 Max. Output Power @ 4Ω
(3)
230V 4,5 725 2 x 125 444 1515
1/8 Max. Output Power @ 4Ω
(3),(5)
254V 4,8 838 2 x 151 536 1827
Normal Mode (-10dB) @ 4Ω
(1)
230V 3,6 558 2 x 100 358 1222
Rated Output Power (0dB) @ 4Ω
(1)
230V 15,1 2750 2 x 850 1050 3583
Alert (Alarm) Mode (-3dB) @ 4Ω
(1)
230V 10,9 1905 2 x 425 1055 3600
Max. Output Power @ 2Ω
(1)
230V 25,4 5255 2 x 1500 2255 7694
1/8 Max. Output Power @ 2Ω
(1)
230V 6,0 1008 2 x 188 633 2160
1/8 Max. Output Power @ 2Ω
(2)
230V 6,5 1119 2 x 188 744 2539
1/8 Max. Output Power @ 2Ω
(3)
230V 6,5 1086 2 x 188 711 2426
(1) Sine Modulation (1kHz) (2) VDE-Noise (3) pink-Noise EN60065 / 7. Edition
(4) 1BTU = 1055.06J = 1055.06Ws (5) 10% Mains Over Voltage (6) Pd = Leakage Power
The following factors allow direct proportional calculation of the mains current Imain for different mains supply voltages:
100V = 2.3; 120V = 1.9; 220V = 1.05; 240V = 0.96
