PowerH SERIES
Owner’s Manual 9
Factory Settings
2.2 Operating Voltage
The power amplifier receives its power supply via the MAINS IN connector, which is designed as a Neutrik
PowerCon® connector.
Control Setting
Mains Switch off
Level CH A 0dB
Level CH B 0dB
Table 2.1: Factory Settings of the Controls
Parameter Value
Power-On-Delay 0.00 s
Breaker Current (dependent on the mains) 16 A (230 V) / 30 A (120 V)
Amplifier Name Dynacord H2500 or Dynacord H5000
LCD Contrast 50%
LCD Brightness High 90%
LCD Brightness Low 40%
LCD Time to Dim Autodim off
Temperature Unit °C
Table 2.2: Factory Settings of the LC-Display
Controls Setting
ROUTING DUAL
MODE NORMAL
SENSITIVITY/GAIN 0dBu
GROUNDLIFT GROUNDED
Table 2.3: Factory Settings of the Rear Panel Controls
CAUTION:
The Powercon
® is a connector without breaking capacity, i.e. the Powercon® should
not be connected or disconnected under load or live.
