Dynacord S 90 Service Manual

Ersatzteilliste - Bill of Materials
112609
S 900 POWER-AMP
Pos. Nr.
Ref. No.
Best. Nr.
Part No. Bezeichnung Description
Zubehör
Accessories & packing material
355637 BEDIENUNGSANL. S 900/1200 owner's manual
300425 KABEL-NETZ 2.0 M 10A power cable Europe
349528 HUTSTOPFEN H7 18,5MM plug, hole
337053 SCHUTZHÜLLE 650X800X0,08 poly bag
353105 KRT. 2 HE "DY." 556X507X178 carton
355741 STYROPOR-EINLAGE S900/Q44 filler, foam
359625 STYROPOR-PL. 500X370X20 filler, foam plate
Mechanische Teile
Cabinet material
B0010 341343 BUCHSE-SPEAKON-VIERECK 4POL speaker socket 4-pole
G0010 343270 GLRI GBPC 3504 rectifier GBPC-P 3504
S0010 346720 SCHALTER-NETZ ESB-99888V power switch
335589 FUSS-GUMMI SJ 5009 SW rubber foot
341382 KNOPF-TASTE 20X8 SW 3.3 push button black
355604 DK 22 SW/LG C 6FL knob rotary
348415 LÜFTER TYP FBAO8A24H DC fan dc 24V
349693 KABEL-KONFEKT 4POL 0.670M ribbon cable assy 4-way
344842 KABEL-KONFEKT 8POL 0.140M ribbon cable assy 8-way
349612 KABEL-KONFEKT 8POL 0.400M ribbon cable assy 8-way
355635 FB.S 900 BED front panel
355636 RW.S 900 BED rear panel
351353 DEC.3HE DEM-LAC/L16-2400LAC top cover chassis
354549 NT-RG.Q44/S900/CPS1 230V power transformer 230V
348805 WI-SO PTC K155 100GRAD safety component PTC
348341 FEDERLEISTE 3POL CE100- connector female 3-pole
Platinen, bestückt
Printed circuit boards assy
841718
PCBAR#S 900
pcb s/a 84171
CNAC1 343516 FL.STECKER 4.8/0.5 connector 4.8mm faston
CNAC2 343516 FL.STECKER 4.8/0.5 connector 4.8mm faston
CNGND 343516 FL.STECKER 4.8/0.5 connector 4.8mm faston
CNGN1 330269 FL.STECKER 6.3/0.8 connector 6.3mm faston
CN001 344862 MESSERLST. 8POL connector male 8-pin
CN002 348334 STIFTLEISTE 3POL MLSS connector male 3-pin
CN003 348334 STIFTLEISTE 3POL MLSS connector male 3-pin
CN005 348334 STIFTLEISTE 3POL MLSS connector male 3-pin
CN007 330269 FL.STECKER 6.3/0.8 connector 6.3mm faston
CN01X 344862 MESSERLST. 8POL connector male 8-pin
CN010 330269 FL.STECKER 6.3/0.8 connector 6.3mm faston
CN013 330269 FL.STECKER 6.3/0.8 connector 6.3mm faston
CN018 341937 MESSERLST. 4POL connector male 4-pin
CN019 330269 FL.STECKER 6.3/0.8 connector 6.3mm faston
CN020 344862 MESSERLST. 8POL connector male 8-pin
CN08X 343516 FL.STECKER 4.8/0.5 connector 4.8mm faston
