21
Turn the power “OFF” before conducting any maintenance procedures.
TOOLS REQUIRED:
HOW TO REPLACE FRONT WHEELS
1. Remove the axle cap with a flat head screwdriver.
2. Remove the M10 locknut with a 17mm socket wrench.
3. Remove the Ø12 washer.
4. Remove the wheel, then replace with a new one and make sure the Ø12 bushing
sits inside the wheel.
5. Remount the Ø12 washer, M10 locknut and securely tighten the wheel; then
re-insert the axle cap.
Flat head Screwdriver
(not included)
17mm Socket Wrench
(included)
Wheel
Axle capBushing
Ø12 Washer
Ø12 Washer
M10 locknut
Wheel
axle
DETAILED MAINTENANCE AND REPAIR
