4.1 Controls and Indicators
4.1.1 Operator Control Panel
The operator control panel is ergonomicall fitted so as to provide the operator with the
necessar controls to operate the machine at an arms reach
Figure 4-1 Control anel
Item
Text
Description
1
L
Selects rotation direction
2
SD CTL
Speed of rotation
3
STAT
Starts the machine
4
ST
Stops the machine
Table 4-1 Description of the Control anel
