DYNAMIC DIAMOND TOOLING Beast - Page 15

6
5
2
1
3
4
8
7
3.2 Machine Overview – Left Side
Figure 3-2 Machine overview – Left Side
Item
Description
1
Cup Holder
2
Handle Tilt Adjustment
3
Handle Height Adjustment
4
Foot Hold to Tilt Machine back
5
Grinding Head Level Adjustment Bolt
6
Grinding Head Level Indicator
7
Grinding Head
8
Transport Handle
Page 9
Dynamic Diamond Tooling
DDG 1220 User Manual
1
2
3
4
5
6
7
8
rottle Control
Handle Tilt Adjustment
Handle Height Adjustment
