STEP 3
Grinding Head Alignment Indicator shows position of h ea d
NOTE: Black or Blue Line indicates position of h e ad.
Grinding H e ad p osi t io n CTD
(black li ne ali gne d w i th h ol e )
Grinding H e ad p osi t io n f u ll LFT
(black li ne ali gne d w i th l e f t bla ck n o tch m a rk )
Grinding H e ad p osi t io n f u ll IGHT
(black line a li gne d w i th r i ght b la ck n o tch m a rk )
Page 23
Dynamic Diamond Tooling
DDG 1220 User Manual
