Installation, Operation and Service Manual LKAT
2
Portable
© 2018 DynAmp, LLC Page 8
047312 A
2.5 MAINS POWER CABLE ASSEMBLY DETAIL
AC/DC (85 to 264V AC) or 110 to 264VDC Metering Units include:
Mains Power Cable Assembly
This features a keyed circular connector terminating one end for connection to the Metering
Unit Electronics. The other end is unterminated for connection to the power source by the
user during use of the system. The user may install an electrical power plug on the end of
this cable assembly that is appropriate for the site location. Alternatively, this cable
assembly may be directly wired to a circuit breaker or electrical distribution panel.
IMPORTANT NOTE:
Connecting +24VDC Mains Power Cable to a voltage greater than 36VDC or 25VAC will
result in catastrophic, unrepairable damage to LKAT2P Metering Unit. Never terminate
this cable assembly with a “normal” electrical plug used to connect equipment to AC
Mains.
2.6 SYSTEM OUTPUT CABLE ASSEMBLY DETAIL
The LKAT2P system includes two output cable assemblies
Instrumentation Signal Output Cable
A keyed circular connector terminates one end for connection to the Metering Unit
Electronics. The other end exits from a small enclosure with banana jacks for connection to
the user’s measurement instrumentation. There are (4) plug-in adapters tethered to the
cable assembly which may be plugged into the banana jacks on the enclosure. These
convert the system 20mA full-scale output to 1V, 2V 5V or 10V respectively.
Process Signal Output Cable
The process signal output system output cable is a 17-conductor type. .A keyed circular
connector terminates one end for connection to the Metering Unit Electronics. However,
only 8 of the 17 conductors are used when the optional PE pc board assembly is NOT
installed. The unused conductors may be trimmed flush to cable jacket. The user may
install ferrules or lugs on the stripped wire ends of the cable. These should be appropriate
for connection to the appropriate inputs during use.
