11
LG140/160/200 ILG140EN4
TECHNICAL DATA
LG140 LG140 LG160 LG160
Honda Hatz Honda Hatz
Weight
Net weight, kg (lbs) 152 (335) 164 (362) 156 (344) 169 (373)
Operating weight, kg (lbs) 154 (339) 166 (366) 158 (348) 171 (377)
Compaction data
Vibr.frequency, Hz (vpm) 65 (3900) 65 (3900) 82 (4920) 82 (4920)
Centrifugalforce, kN (lbf) 22 (4945.8) 22 (4945.8) 35 (7868.31) 35 (7868.31)
Amplitude, mm (in) 2,0 (0.08) 2,0 (0.08) 1,7 (0.07) 1,7 (0.07)
Operating data
Speed of travel, m/min (ft/min) 0-25 (0-82) 0-25 (0-82) 0-25 (0-82) 0-25 (0-82)
Max. tilt, ° 20 20 20 20
Volumes
Fuel tank, lit. (qts) 3,6 (3.8) 3,6 (3.8) 3,6 (3.8) 3,6 (3.8)
Crank case, lit. (qts)
SAE 15W/40 0,6 (0.63) 0,9 (0.95) 0,6 (0.63) 0,9 (0.95)
Hydraulic fluid, lit. (qts)
Shell TX32 1,0 (1.0) 1,0 (1.0) 1,0 (1.0) 1,0 (1.0)
Eccentricelement, lit. (qts)
SAE 10W/30 0,4 (0.42) 0,5 (0.53) 0,4 (0.42) 0,5 (0.53)
Engine
Model Honda Hatz Honda Hatz
GX160 1B20 GX160 1B20
Recoil start Recoil start Recoil start Recoil start
Output, kW (hp) 4,1 (5.5) 2,8 (3.8) 4,1 (5.5) 2,8 (3.8)
Engine speed, rpm 3600 2600 3600 2600
Noise and Vibrations
Noise level Sound pressure level at the operator's ear according to ISO 6394:
L
pA
dB (A) = 90 90 92 90
Sound power level according to ISO 3744:
L
wA
dB (A) = 110 104 107 104
Vibration values The hand - arm vibration values according to ISO 5349:
a
m/s
2
= 0,6 1,9 1,4 3,1
The above noise level and vibration values were determined at normal speed of the engine with
vibration on. The machine was placed on an elastic base.
During operation these values may differ because of the actual operational conditions.
