14
LG140/160/200 ILG140EN4
OPERATION – HONDA GX160/GX200
1. Fill fuel tank.
Tank volume 3,6 lit. (3.8 qts)
2. Check oil level in engine crank case.
Oil volume 0,6 lit. (0.65 qts)
Before start
Starting the engine
4. Open throttle fully. Move the choke valve to the close
position. Do not use the choke if the engine is warm
or the air temperature is high.
5. Turn the start button to position I.
Min.
Max.
OK
3. Open the fuel cock and open the throttle fully.
21
3
5
4
L000509A
L000512A
L000064A
L000039A L000077A
To Next Page
