18
LG140/160/200 ILG140EN4
OPERATION – ALL ENGINE TYPES
Operating
Drive direction and speed are infinetely variable with
the hydraulic lever.
1. Forward (the hydraulic lever is pushed forward with
small movements).
2. Reverse (the hydraulic lever is pushed backwards
with small movements).
3. Stationary (the hydraulic lever is moved with small
movements in the opposite direction until the machi-
ne is stationary).
1
2
3
1
L000509A
L000511A
1. Open throttle fully.
During compaction work the engine must always
run at full throttle.
