OPERATING INSTRUCTIONS
SMARTRAC | OPERATOR’S MANUAL REV. 0 | 4/06/2018 10
Operating Instructions
Operator Controls
1. Cord
2. Pulley
3. Display with Touch Screen
4. Power Switch
0 Device disconnected from power supply
1 Device connected to power supply touch screen
5. Power Input and Power Fuses
6. Type Number Plate
Provides device information: type and serial
number, as well as data on voltage and maximum
current consumption.
7. Patient Stop Switch Connection
8. Remote Control Connection
Basic Operation
Switch on the device “ON” using the Power Switch located on the back of the console (#4).
