REPLACEMENT PARTS DIAGRAMS
DYNATRON® T3™ HI-LO TREATMENT TABLE & T4™ TRACTION TABLE | OPERATOR’S MANUAL REV. 10 | 4/4/2018 16

No. Part Numbers View A Description
3 T4-TOP(color)-B Top Mid-Section
13 40-106-B Magnetic Mid-Li Motor Max 10
14 T34MSL Mid-Li Switch Le
16 35-005 Mid-Section Gatch Mechanism Spring
17 DP000061 Master Gatch Mechanism Wieldment (controls all three sections)
REF

View A enhancement with Mid-Li Motor.
View A enhancement without Mid-Li Motor.
