Dynaudio 9S Owner's Manual

System Active subwoofer
Bass principle Closed
Frequency response 22Hz to 175Hz (±3 dB)
Inputs – LFE/Slave XLR
Inputs – SAT/SUB Right/left full bandwidth, XLR
Input impedance – + branch 20kOhm
Input impedance – - branch 10kOhm
Max. input voltage 10 VRMS
Outputs – Slave XLR
Outputs – SAT/SUB Right/left, Highpass ltered, XLR
Output impedance 100Ohm (each branch)
XLR Pinout 1 = 0 / 2 = + / 3 = –
Mode selector LFE, Slave (Phase and volume controls are bypassed in slave mode)
Phase adjustment 0°, 180°
Highpass Flat, 60Hz, 80Hz
Lowpass 50Hz to 150Hz
Power modes On, Auto
Amplier power 300W, 4Ohm
Power consumption – Standby < 0.5W
Power consumption – max. 325W
Woofer – Cone 300mm/12in, long-throw, one piece moulded MSP (Magnesium Silicate
Polymer) cone
Woofer – Coil 75 mm / 3”, pure aluminium voice coil
Dimensions, external (Depth x Width x Height) 412 x 350 x 350 mm (including cloth cover)
Cabinet volume 31 litres
Weight 18.4kg
Mains – 100-120 V / 220-240 V, 50/60Hz 1 Fuse = 3.15A
Technical specications
3130
Technical specications

Dynaudio 9S Specifications

General

System	Single driver, active 9, 5 in subwoofer
Analog inputs	1 x XLR LFE, 2 x XLR Stereo
Analog outputs	1 x XLR Slave Out, 2 x XLR SAT Out
XLR Pinout	1 = 0 / 2 = + / 3 = –
Input impedance – + branch	20 kOhm
Input impedance – - branch	10 kOhm
Frequency response (± 3 dB)	22 Hz – 175 Hz
Box principle	Sealed
Max. input voltage	10 VRMS
Auto ON/OFF	Yes
Amplifier power	300 W
AC power input	100-120 V/200-240 V 50/60 Hz
Standby power consumption	< 0.5 W
Maximum power consumption	350 W
Output impedance	100 Ohm (each branch)
Max SPL	106 dB
High pass filter	Flat / 60 / 80 Hz
Low pass filter	50 Hz -150 Hz
Phase adjustment	0/180 degrees
Woofer	24 cm MSP
Mode selector	LFE, Slave (Phase and volume controls are bypassed in slave mode)

Weight and Dimensions

Weight	10.5 kg / 23.1 lb
Dimensions (W x H x D)	266 x 276 x 320 mm / 10.5 x 10.9 x 12.6 in
Shipping box dimensions (W x H x D)	400 x 430 x 400 mm / 15.7 x 16.9 x 15.7 in
