Dynaudio 9S Owner's Manual

2120
Operation
Operation
Switching the subwoofer on
Once you have ensured yourself that
all necessary connections have been
made, the subwoofer and the connected
components can be switched on.
1. Connect the subwoofer to the mains
power.
2. Switch the subwoofer on with the
main POWER switch on the rear
panel.
3. The status LED on the rear of the
subwoofer will light up red.
4. Select a power mode with the Power
switch on the rear panel.
Power modes
• On: the subwoofer is switched on
permanently
• Auto: when a music signal is
detected, the internal amplier is
activated automatically. The status
LED on the back of the subwoofer
will light up green. As long as a
music signal is available on the
subwoofer’s input, it will remain
switched on.
• After 15 to 20 minutes of not
sensing any input music signal,
the subwoofer will switch itself
to Standby mode automatically.
The status LED on the back of the
subwoofer will light up red.
Note
To switch the subwoofer
completely off, set the main
POWER switch to the OFF position.
ON AUTO
GAIN PHASEPOWER
SUB LowpassSAT Highpass
SAT/SUB Input SAT Output
LFE / Slave IN OUT
Min Max
50Hz 150Hz
0° 180°
LEFT
RIGHT
SUB I/O To Slave
LFE Slave
~ 50/60Hz 3.15A
FUSE T3.15A L 250V
OFF
ON
60HzFlat 80Hz
ON AUTO
GAIN PHASEPOWER
SUB LowpassSAT Highpass
SAT/SUB Input SAT Output
LFE / Slave IN OUT
Min Max
50Hz 150Hz
0° 180°
LEFT
RIGHT
SUB I/O To Slave
LFE Slave
~ 50/60Hz 3.15A
FUSE T3.15A L 250V
OFF
ON
60HzFlat 80Hz
2.
3.
1.
4.

Dynaudio 9S Specifications

General

System	Single driver, active 9, 5 in subwoofer
Analog inputs	1 x XLR LFE, 2 x XLR Stereo
Analog outputs	1 x XLR Slave Out, 2 x XLR SAT Out
XLR Pinout	1 = 0 / 2 = + / 3 = –
Input impedance – + branch	20 kOhm
Input impedance – - branch	10 kOhm
Frequency response (± 3 dB)	22 Hz – 175 Hz
Box principle	Sealed
Max. input voltage	10 VRMS
Auto ON/OFF	Yes
Amplifier power	300 W
AC power input	100-120 V/200-240 V 50/60 Hz
Standby power consumption	< 0.5 W
Maximum power consumption	350 W
Output impedance	100 Ohm (each branch)
Max SPL	106 dB
High pass filter	Flat / 60 / 80 Hz
Low pass filter	50 Hz -150 Hz
Phase adjustment	0/180 degrees
Woofer	24 cm MSP
Mode selector	LFE, Slave (Phase and volume controls are bypassed in slave mode)

Weight and Dimensions

Weight	10.5 kg / 23.1 lb
Dimensions (W x H x D)	266 x 276 x 320 mm / 10.5 x 10.9 x 12.6 in
Shipping box dimensions (W x H x D)	400 x 430 x 400 mm / 15.7 x 16.9 x 15.7 in
