Dynaudio Xeo 10/20/30
2928
Direct wired:
Analog/digital audio sources
+ Xeo 10/20/30
Direct wireless:
Bluetooth device (mobile phone, etc.)
+ Xeo 10/20/30
With Hub or Connect:
Analog/digital audio sources
+ Hub or Connect + Xeo speaker
For extended range:
Analog/digital audio sources
+ Hub or Connect + Extender + Xeo speaker
For additional speakers:
Analog/digital audio sources
+ Hub or Connect + Xeo speaker plus
+ Link + active component (e.g. active subwoofer,
active speakers, or power amplier and passive speakers)
Combination examples
Below you will nd several examples of Xeo component combinations. The high level of
exibility in the Xeo system enables even more variants. Ask your Dynaudio distributor
to nd the perfect solution for your needs.
Note: The Extender and Link may also be combined.
Connection options
