Connecting and establishing a link
Hub
Link
1. Connect the Power socket to the voltage supply via the Xeo power supply unit.
Do not use a different power supply unit!
2. Select an audio zone: Red, Green, or Blue.
Use one of the outputs to connect the Xeo Link with one of the active components, e.g. the active
subwoofer Dynaudio Sub 600.
3. Select the desired signal source with the remote control and control the volume.
NOTES:
You can assign the Xeo Link to an audio zone the same way as with the Xeo 4 and Xeo 6
loudspeakers and then control it specically via the remote control.
A Xeo loudspeaker can also be used parallel to the Xeo Link.
Several active components can be connected to the Xeo Link. The signal is then output in parallel on
all analog and digital outputs.
The Xeo Link can also be used in conjunction with the Xeo Extender. The settings are identical for
using the Xeo Extender and a Xeo loudspeaker.
