Technical data
Loudspeakers Xeo 4 Xeo 6
Frequency range (± 3 dB) 45 Hz – 23 kHz 31 Hz – 23 kHz
Power consumption during operation 5 – 38 W 7.4 – 77 W
Power consumption in standby 0.34 W (with active network) 0.35 W (with active network)
Amplier performance Woofer: 50 W, tweeter: 50 W Woofer: 2 x 50 W, tweeter: 50 W
Dimensions (W x H x L) 170 x 282 x 246/246 mm 170 x 854 x 246 mm
Weight 6.4 kg 14.7 kg
Voltage supply 100 – 240 V, 50/60 Hz 100 – 240 V, 50/60 Hz
Xeo Hub Xeo Extender Xeo Link
Signal frequencies A: 2.4 GHz, B: 5.2 GHz, C: 5.8 GHz*
Sampling rate for digital inputs Up to 24 bits/96 kHz – –
Input voltage (typ.) RCA: 1 V
rms
Mini jack: 250 mV
rms
– –
Input impedance RCA: 11.4 kΩ
Mini jack: 8.2 kΩ
– –
Dimensions (W x H x L) 140 x 32 x 105 mm 120 x 32 x 90 mm 120 x 32 x 90 mm
Weight 0.2 kg 0.16 kg 0.16 kg
Voltage supply Adapter: 100 – 240 V, micro USB: 5 V/min. 500 mA
* If available
