52
Switching
between the digital
signal inputs
Control of the heights
MODE/ (8)
TREBLE
(12)
Switches between SD, USB and BT (AUX3).
Holding this button turns off or on the MP3-Player.
Turn the knob "TREBLE" on the front panel to control the amount
of high tones in the sound. Clockwise rotation amplifies the set
intensity. Movement in the counterclockwise direction decreases the
intensity. In the center position, the heights of the input signals
remain unchanged. The tone control affects the signals from the
speaker terminals (19), the headphone (9) and the pre-amplified
signal output "PRE-OUT" (18).
Operation Button(s) Description
