A48100 Unit User Manual
5
2 Product Specification
2.1 Size and Weight
Table 2-1 A48100 Device size
2.2 Performance Parameter
Table 2-2 A48100 performance parameter
Item
Parameter value
Nominal Voltage(V)
48
Work Voltage Range(V)
42~54
Nominal Capacity(Ah)
100
Nominal Energy(kWh)
4.8
Recommended Charge/Discharge Current (A)
50
Max. Power Charge/Discharge Current (A)
75
Peak Power Charge/Discharge Current (A)
100 (15S)
Charge Voltage (Vdc)
53.5
2.3 Interface Definition
This section elaborates the interface functions of the front interface of the device.
Figure2-1 The sketch of interface.
Product
Nominal
Voltage
Nominal
Capacity
Dimension
Weight
A48100
DC48V
100Ah
504×597×155mm
≈45kg
1
2
4
3
6
5
7
8
9
10
11
12
