EFIS
-D100 Pilot’s User Guide 4-1
4. AVAI LABLE PAGES
The EFIS main pages use various tapes, digital displays, and other indicators overlaid on an artificial horizon. On the 2/3
and full-screen pages, you may also display up to two “info items” on the left and right side of the main page. HSI pages
use text and a DG style compass by itself or overlaid with lines and arrows of different colors.
Note: HSI pages use data that is obtained from a source exter
nal to the EFIS-D100. Refer to the EFIS-D100
Installation Manual for a list of compatible equipment.
Note: EMS-based pages use data that is obtained from Dynon’s EMS products. You may only display these pages
on
your EFIS-D100 if you own a Dynon EMS-based product, and the two units are connected via DSAB. Refer to
the EFIS-D100 Installation Manual for details regarding proper connection between Dynon products and other
devices in your system. Please see your EMS-based product’s Pilot’s User Guide for information on configuring
the various displays sourced from it.
