Product Operation
The EFIS-D100 has several pre-defined screen configurations.
The basic layout of a screen configuration is represented by one
of three icons on D100-series product. The table at right shows
the three icons and their meaning.
The predefined screen configurations with their respective icons
are as follows:
EFIS/EMS
EFIS/AUX
EFIS/FUEL
EFIS/TIMES
EFIS/HSI (in default screen rotation)
EMS/EFIS
EMS/AUX
EMS/TIMES
EMS/FUEL
EMS/HSI
EFIS (default EFIS-D100 boot-up screen; in default rotation)
EFIS/EMS
EMS/EFIS
HSI/EMS
EFIS-D100 Pilot’s User Guide 3-
3
Icon Left Page Area Right Page Area
2/3 1/3
1/3 2/3
One page that occupies all of the screen
area
The SCREEN LIST Menu uses icons to illustrate the
layout for each screen configuration.
