Appendix
9-8 EFIS-D100 Pilot’s User Guide
Appendix D: EFI S-D100 Specifications
Mechanical
Mounting: 6.95” wide x 4.90” tall x 4.51” deep (177 x 125 x 115 mm)
Weight: 2 lb 13.5 oz. (1.29 kg)
3 lb 4 oz. (1.47 kg) with internal battery
AP74: 10.7 oz.
HS34: 11.3 oz.
Operating Temperature
-22° to 122° F (-30° to 50° C)
Power
Voltage: 10 - 30 Vdc
Power: 12 watts t
ical; 17 watts maximum
Connections
Wiring: D-25 male
Screen
Type: AMLCD, TFT (Thin Film Transistor)
Backlight: 400 nits or 800 nits
Size: 7.0” diagonal (178 mm)
Resolution: 854 x 480 color pixels
