Product Operation
The EMS-D10 has several pre-defined screen configurations. The
basic layout of a screen configuration is represented by one of two
icons on D10-series product. The table below shows the two icons
and their meaning.
Icon Left Page Area Right Page Area
1/2 1/2
One page that occupies all of the screen
area
The predefined screen configurations with their respective icons
are as follows:
EMS (default EMS-D10 boot-up screen; in default rotation)
TIMES/AUX (in default screen rotation)
FUEL (in default screen rotation)
EFIS
HSI
EMS-D10 Pilot’s User Guide 3-3
The SCREEN LIST Menu uses icons to illustrate the
layout for each screen configuration.
