EMS Operation
EMS-D10 Pilot’s User Guide 7-5
Global Configuration Settings
Configure global settings: EMS >SETUP > GLOBAL
The Global page is divided into three sections: PILOT SETUP, SCREEN SETUP, INSTALL SETUP, and LOCAL
SERIAL PORT. Pilot settings and screen settings are addressed in this guide. If you or your installer have completed the
procedures outlined in the EMS-D10 Installation Guide, you do not need to modify anything in the other sections.
Scroll between settings by using the UP▲/ DOWN▼ buttons. Chosen settings are highlighted. Toggle between
parameter settings or display a menu of choices by pressing SEL►. Press BACK to save.
Change displayed indicator units: EMS > SETUP > GLOBAL > UNITS►
In the UNITS submenu, you may change the system-wide displayed units for a variety of parameters. See the following
table for a list of available units.
In a DSAB network, unit preferences are shared between all connected instruments.
Parameter Available units
Manifold Pressure inHg, mbar
All other engine pressures PSI, bar
Volume Gallons, liters
Engine Temperature Fahrenheit , Celsius
Distance Nautical miles, statutory miles, kilometers
Speed Knots, miles/hour, kilometers/hour
Altitude Feet, meters
OAT temperature Celsius, Fahrenheit
Barometer pressure inHg, mbar
